Components
2 x 2267H 15″ Differential Drive® LF
4 x 2169H 8″ Differential Drive® MF
3 x 2430K D2 Dual Compression Driver
Horizontal Coverage (-6 dB): 90 degrees nominal (250 – 16k Hz)
Frequency Range (-10 dB): 35 – 20k Hz
Frequency Response (+/-3 dB): 41 – 18k Hz
Sensitivity (1W/1m): 99 dB LF, 103 dB MF, 116 dB HF
Nominal Section Impedances: 2 x 8 ohms LF, 8 ohms MF, 8 ohms HF
Continuous Power Rating: 4000W LF, 1400W MF, 600W HF
Dimensions: 48.11″W x 16.28″H x 24.14″D (1222 x 413.5 x 613.2 mm)
Weight: 192 lbs (82.5 kg)
