Output
Beam Angle: 23° / 10°
Lumens†
1469 (23° beam angle)
1679 (10° beam angle)
Color Temperature: 2700 K (+/- 145) – 6500 K (+/- 275)
Efficiency (Lm/W)
29.4 (23° beam angle)
33.6 (10° beam angle)
Mixing Distance: 6″ to uniform light
CRI: 83 all, 83 warm, 74 cool
Lumen Maintenance‡: 70,000 hours L70 @ 25° C (typical application)

Electrical
Input Voltage: 24 VDC via PDS-750 TR
Power Consumption: 50 W maximum at full output, steady state

Control
Interface: PDS-750 TR
Control System: Philips full range of DMX controllers, or other third party DMX controllers

Lens
Frosted glass (23º)
Clear glass (10º)
Fixture Connections: 6′ power / data cable with 4-pin XLR connector

Temperature
Operating: -40° – 122°F
Startup: -4° – 122°F
Humidity 0 – 95%, non-condensing
Environment: Dry Location, IP20

Physical
Housing: Die-cast aluminium, black powder-coated finish
Maximum Cable Length: Up to 54′ extension for total of 60′ maximum

Certification and Safety
Certification: UL / cUL, FCC Class B, CE
LED Class: Class 2 LED product

† Lumen measurement complies with IES LM-79-08 testing procedures
‡ L70 = 70% maintenance of lumen output. (When light output drops below 70% of initial output.)
